High quality 11KW MPPT Solar Inverters ac to ac 380V output ac motor drive
EM15-SP series solar inverter is high-efficiency solar water pump controller, which with high MPPT efficiency, green environmental protection, economic and energy saving, widely use for agricultural irrigation, water supply system and etc.
Products Feature:
Support voltage and power range: Single phase or three phase 220V, Three phase 380V; Power is from 0.75kW to 400KW.
Easy to use, built in water pump protection functions.
The water level detection functions, which can support terminal /analog detection.
PV power, PV current, pump flow rate and other operating parameters are accurately displayed.
All series of products can realize the switching of AC power supply or PV power supply to meet the 24-hour work;
Accurate and fast MPPT algorithm tracking PV battery maximum power point, ensure 99% solar power tracking efficiency.
Support for basic function of inverters, such as terminal control start and stop, RS485 communication, which can remote operation and monitoring.
Battery-free design, suitable for various applications, easy to maintain.
Perfect protection function: with automatic dormancy function, low frequency protection, overcurrent, overload protection and other protection functions, can effectively prolong the product life.
EM15-SP3 Description | d75 | 1d5 | 2d2 | 004 | 5d5 | 7d5 | 011 | 015 | 018 | 022 | 030 | 037 | 045 |
| 055 | 075 | 090 | 110 | 132 | 160 | 200 | 220 | 250 | 280 | 315 | 355 | 400 |
| DC input (+, -) |
| Rated power/KW | 0.75 | 1.5 | 2.2 | 4 | 5.5 | 7.5 | 11 | 15 | 18.5 | 22 | 30 | 37 | 45 |
| 55 | 75 | 90 | 110 | 132 | 160 | 200 | 220 | 250 | 280 | 315 | 355 | 400 |
| Min. DC voltage/V | 280 |
| Max.DC voltage/V | 750 |
| Recommended MPPT range /V | 350~750 |
| AC output(U, V, W) |
| Output current | 2.1 | 3.8 | 5.1 | 9 | 13 | 17 | 25 | 32 | 37 | 45 | 60 | 75 | 91 |
| 112 | 150 | 176 | 210 | 253 | 304 | 377 | 426 | 465 | 520 | 585 | 650 | 725 |
| Output frequency | 0~50/60Hz |
| Power factor | >0.99 |
| Communication mode | RS485 communication |
| Protection class | IP20 |
| Ambient temperature | -10℃~ +40℃(ambient temperation at 40℃~50℃,please keep derated use) |
| Storage temperature | -20℃~ +60℃ |
| Humidity | Smaller than 95%RH, non-condensation |
| Cooling | Forced Air cooling |
| Altitude | Lower than 1000 m |
| Humidity | Less than 95%RH, without condensing |
| Vibration | Less than 5.9 m/s2 (0.6 g) |
Q&A
What can you buy from us?
Soft Starter, Frequency Inverter, Servo motor and drive.
How can we guarantee quality?
EMHEATER frequency inverter passed IEC test and has CE certificate. Each piece of VFD will have 4 testing before delivery, follow ISO 9001 standard. We offer high quality VFD.
What's the delivery term?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,FCA,CPT,DDU, etc
Product Tags:
|
|
350V To 750V 25A MPPT 11kw Solar Inverter Ac To Ac Images
|
